Hello everyone ! Today I want to write a bit of explanation on one of the core smt operations:

<center> smt_setup_emissions </center>

This operation is used, as it's name hints, to setup emission/inflation for an smt. In order to use it you must have previously called the `smt_create operation` to create an smt object in the chain to send this operation on.

Now let's look at the operation and it's parameters :

```
  account_name_type   control_account;
   asset_symbol_type   symbol;

   time_point_sec      schedule_time;
   smt_emissions_unit  emissions_unit;

   uint32_t            interval_seconds = 0;
   uint32_t            interval_count = 0;

   time_point_sec      lep_time;
   time_point_sec      rep_time;

   share_type          lep_abs_amount;
   share_type          rep_abs_amount;
   uint32_t            lep_rel_amount_numerator = 0;
   uint32_t            rep_rel_amount_numerator = 0;

   uint8_t             rel_amount_denom_bits = 0;
   bool                remove = false;
   bool                floor_emissions = false;

   extensions_type     extensions;
```

You can find this in : https://github.com/steemit/steem/blob/master/libraries/protocol/include/steem/protocol/smt_operations.hpp

# the basics

So first of all, you need to give the operation the information about which smt you want to add emission to :

(note that the code examples will be in js from now on)

this is where you set

- control_account
with, for example : "howo"

- symbol
it's an `asset_symbol_type` which is a struct with a nai and a precision, so it would be akin to something like

 `{'nai': @@280090049, 'precision': 13}`

- schedule_time

This is where you state when the emission starts, there is no end date for the emissions unless you set it in another emission call (we'll get to that later on)

## Emission units

This is where we start to dive into the interesting parts, emission units define where the inflation actually goes, the structure looks like this :

```
[
    ['howo', 50],
    ['steempress', 50],
]
```

And that's it ! Here I state that every time there is an emission, 50 tokens will go to me and 50 will go to steempress, you can put steem accounts and there are also three special strings that you can use :

`$market_maker` : inflation will go to the decentralized market in order to provide liquidity early on
`$rewards`: Fund the reward pool for your smt, if you don't set this,  your token won't have proof of brain rewards via inflation (you could fund that account via other means like the ico)
`$vesting`: Fund the vesting rewards

Since the parameter is an array you can set several inflation destination at the same time.

## Interval_second and interval_count

Okay so we emit x tokens to those emission sources, but how how often ?

`interval_seconds` sets how often emissions will be triggered, note that the minimum is 21600, aka 6 hours.
`interval_count` sets a limit on how many times you want to emit.

if you set it to 10 you will only emit 10 times. It's a good way to set a limit to your inflation, or to get all the tokens at once in everyone's hands.

## Variable emissions, because otherwise it would be too easy

This is where things get tricky, and I am not 100% sure myself but here's the gist of it, you can refer to the official smt documentation as well if I'm not making enough sense : https://github.com/steemit/smt-whitepaper/blob/master/smt-manual/manual.md#adding-time-modulation

you can set curves for your inflation, in order to have, let's say a decreasing inflation.

for that you have `lep_time` and `rep_time` to set both ends of the curve, lep stands for left end point, rep right end.

values are like this : `1970-01-01T00:00:00`

Side note :

- For times before the left endpoint time, the amount at the left endpoint time is used.
- For times after the right endpoint time, the amount at the right endpoint time is used.

Then you have 4 parameters :

`lep_abs_amount` and `rep_abs_amount` which are the values taken at lep and rep from which we'll get a curve (100 and 0 for instance to make inflation go to 0 over time).

Abs use integer values aka 10, 20, 30

`lep_rel_amount_numerator` and `rep_rel_amount_numerator`which are the same except that they use a different calculation to take advantage of decimals. Hence why they also have the `rel_amount_denom_bits`to bitwise righ shift the value by the number defined.

So do we need to have both defined and what happens if we only want to set the abs and leave the rel alone ? This is where the `floor_emissions` parameter comes in handly. this is basically what it does :

```
      if ( emission.floor_emissions )
         new_token_supply = std::min( abs_amount, rel_amount );
      else
         new_token_supply = std::max( abs_amount, rel_amount );
```

If floor emission is set to true, it will take the minimum value between the calculated absolute value and the calculated relative value otherwise it will take the biggest of the two. So if you want to use only abs emission, set `lep_rel_amount_numerator` and `rep_rel_amount_numerator` to 0 and  `floor_emissions` to false.


# Adding multiple emissions

phew almost done !  Now here's an interesting thing about emissions, you don't have to have a single emission model, you can have several ones ! So you can reward early adopters with a high reward pool inflation and then switch to a model where it's more normal but inflation to vesting is now favored.

You can have as many inflation as you want but they need to be 6 hours apart from each others.

# Deleting an emission

Finally there is one last parameter : `delete` if set to true, it will delete the emission model that you previously submitted. Quite useful if you found out that there is a parameter that isn't right huh ?

# conclusion

You can find a complete example for this on my hard fork 23 tests here : https://github.com/drov0/hf23-testing/blob/master/bulk_full_setup.js
