Data Requirement for Wellbore Stability Analysis
![](https://cdn.steemitimages.com/DQmVbL2hLwpg5iHRRgjPK7jngxPDvsQ42ptjbrxMFtU9mqW/image.png)
[SOURCE](https://encrypted-tbn0.gstatic.com/images?q=tbn:ANd9GcQiWHZzXc3UjYiPddWAlkILlk0VuB_e_M28pTuVAQnKquQKsf8l)

Data preparation is first step in any data based analysis. However, before we discuss about data preparation -it is important to list out the data requirement for Wellbore stability analysis. Below is the list of data requirement:


Planned Well
•	Planned well Location
•	Planned well TD
•	Planned well trajectory
•	Litho column/Formation Tops prognosis

Field
•	Field Layout
•	Full Field Review Report
•	Field Development Plan

Seismic
•	3D Seismic data required covering the available wells (offset/planned well) with the planned well location.
	Migration velocity & Stacking velocity (in ASCII format)
	Final stack data (SEGY) along with interpreted horizons (ASCII)
	Check shot/VSP data at offset well. VSP Corridor stack, if available.

Geology
•	Geological Report
•	Geological Cross-Sectional Map
•	Image Interpretation Reports
•	Formation Tops
•	Stratigraphic Column
•	Structural Map
•	Geology Related Reports/Papers

Drilling
•	Daily Drilling Report
•	End of well report (Well completion Report)
•	Master Log
•	Deviation Survey
•	Stress Measurements (XLOT/LOT/FIT, Mini-Frac)
•	Casing and Cementing Diagram
•	Real-Time Drilling Measurements (ECD, ROP, Hook Load, Pump Rate, Pump Pressure and Torque)
•	Cavings, Cuttings or Caving Pictures

Logs (Wireline and LWD)
•	Sonic Data (DTC and DTS)
•	Electrical Image Data
•	Openhole Logs (RHOB, GR, CALIPER, NPHI, Resistivity or Induction logs)
•	Petrophysical Logs (Volumes, PHIT,PHIE, Saturations)
•	Check Shot/VSP data
•	Formation pressures, Drill Stem Test

Reservoir
•	Reservoir Pressure
•	Well Test Data

Core
•	Core Data (UCS, Friction Angle, Poisson's ratio, Young's  Modulus, Porosity, Density, petrography)

In case all the listed data is not available then Geoscientists from [ShilazTech](http://www.shilaztech.com/ ) will use informations, relations from representative published results.

# Link to previous discussion on this subject #
 [Wellbore Stability Analysis](https://steemit.com/stem/@prameshtyagi/wellbore-stability-analysis).
[ GeoFit - PetroTechnical Analysis Platform That runs in any Browser ](https://steemit.com/antaeus/@prameshtyagi/geofit-petrotechnical-analysis-platform-that-runs-in-any-browser)

Story continues. Keep Steeming

# Any comment related to subject will be upvoted to help improve the discussion and build the community. #
