**Update: After thinking about it, I am including transfers to and from Steem Monsters and Steem-Engine, these are calculating now and will update when the results are in.**

Was having a discussion with Aggroed yesterday about full nodes and the question came up "how much of the network does Steem Monsters and Steem Engine (this includes Tribes) use".  I said probably around 50% sarcastically, I knew that was high but I figured it was still a large chunk.

As I generally like to know things, I decided to figure it out.

# Creating a python script
I wrote a small python script and started monitoring the results.  I used the **ID** field of custom JSON operations to filter transactions.  I know both use custom JSON transactions to interact with the blockchain.  The ID field is used to disclose the type of operation being performed.

Most of the Steem Engine transactions can be collected by watching for the **ssc-mainnet1** ID.  Steem Monsters and Scotbot use many unique IDs.

# Filtering Aggroed's ops and other
I created two lists, `ops_id` and poorly named `not_ops_id`.  I also had two global counters `ops` and `aggroed_ops` which kept track of the total operations and any operations that were related to an aggroed project (Steem Monsters, Steem Engine, and Scotbot).

I then monitored the blockchain filtering just custom JSON operations.  Immediately upon finding a custom JSON transaction I would increase the `ops` variable.  I would then look to see if the ID was in the list of aggreod related IDs.  If so I increased `aggroed_ops` and continued looking for new transactions.

If the operating was not in the list, I then checked the `not_ops_id` list for transactions I knew about and if it was in that list I would just continue monitoring for new operations.  If it wasn't on either list, it means I didn't have it assigned so I printed the operation's ID.  I would stop the program and assign that ID to the appropriate list and start over.

After a few runs, I had most every operation assigned to a list and the program ran without printing any new operations.  There are still some operations I don't have assigned but they didn't appear during the timeframe I ran the program.

# Results
Once I was at this point, I added a print statement to print the variables `ops` and `aggroed_ops` for each JSON entry found.  I also did the formula `round(aggroed_ops/ops*100, 2)` to calculate the percentage for each operation.

Over a short period of time, I found the percentage of total operations would range from **14% to 22%** of all transactions on the blockchain.

Running overnight over almost 300,000 transactions, I ended up with **23.93%**.

```
Total Ops: 299922
Aggroed's Ops: 71773 (23.93%)
```

# Using SteemSQL to analyze the last 30 days
I wanted to refine my answer by checking over the last 30 days.  With access to SteemSQL I could do just that.  It's a lot more complicated but here is the logic I used.

First, I wanted to confirm I got all possible operation IDs.  So I scanned the txcustoms table for any operation that started with `sm_` or `scot` and updated my list to reflect any of the more rare transactions I didn't see.  I picked up a few more Steem Monsters transactions but I had all the Scotbot transactions as there are only a few.

txcustoms has a timestamp field, so it is really easy to just look for the last 30 days of transactions that have any of the above ids in the `tid` field.

The transaction table however only has expiration for a datetime field, while this is helpful it isn't exactly what I am looking for.  It does, however, have a block_num field and we know exactly how many blocks we have in a 30 day period.  Unfortunately, due to the chain halt, this number isn't exactly perfect but should be fine for our purposes.  I added in 12 hours worth of blocks (14,400) to account for chain downtime.

For the last 30 days, there have been 6,435,882 operations using the IDs I know about. Over the last 30 days (minus 12 hours) we have seen 27,261,701 total transactions.

6,435,882 / 27,261,701 * 100 = 23.6%

Over a period of 30 days, we are still in the 23-24% range.  So I would say this is a really good estimate of the percentage of transactions across the entire blockchain.

# Script

This is a quick and dirty script to answer the above question.  You will need beem to walk the blockchain.  I take no responsibility if you develop developer like symptoms.

```
from beem.blockchain import Blockchain
from beem import Steem

ops = 0
aggroed_ops = 0

op_ids = ['scot_claim_token',
          'sm_find_match',
          'ssc-mainnet1',
          'sm_submit_team',
          'sm_open_pack',
          'sm_team_reveal',
          'sm_sell_cards',
          'sm_gift_cards',
          'sm_combine_cards',
          'sm_claim_reward',
          'sm_combine_all',
          'sm_enter_tournament',
          'sm_undelegate_cards',
          'sm_update_authority',
          'sm_start_quest',
          'sm_cancel_match',
          'sm_refresh_quest',
          'sm_purchase_record',
          'sm_cancel_sell',
          'sm_surrender',
          'sm_join_guild',
          'sm_purchase_orbs',
          'sm_open_all',
          'sm_burn_cards',
          'sm_market_purchase',
          'sm_token_transfer',
          'scot_payout_beneficiaries',
          'sm_price_feed',
          'sm_guild_contribution',
          'sm_gift_packs',
          'test-sm_price_feed',
          'sm_delegate_cards',
          'sm_purchase_item',
          'scot_set_vote',
          'scot_create_claim',
          'scot_claim',
          'scotauto',
          'sm_set_authority',
          'sm_card_award',
          'sm_tournament_checkin',
          'sm_update_price',
          'sm_leave_tournament',
          'sm_leave_guild',
          'sm_guild_remove',
          'sm_guild_promote',
          'sm_guild_invite',
          'sm_guild_decline',
          'sm_guild_accept',
          'sm_edit_guild',
          'sm_create_tournament',
          'sm_convert_cards',
          'sm_cancel_match',
          'sm_add_wallet',
          'sm_accept_challenge'
         ]

not_op_ids = ['follow',
              'nextcolony',
              'vote',
              'drugwars',
              'GameSeed',
              'wise',
              'actifit',
              'pm_create_bid',
              'sh_active_user',
              'pm_cancel_bid',
              'sh_active_user',
              'vaporchain',
              'esteem_boost',
              'BandiFight_Fight',
              'start_mission',
              'likwid-beneficiary',
              '3speak-publish',
              'blockchainstudio_gdp',
              'blockchainstudio_fp',
              'BandiFight_Fight',
              'get_new_missions',
              'pm_update_bid',
              'pm_accept_contract',
              'steemfinex',
              'qwoyn_report',
              'poo',
              'pm_new_delegation',
              'pm_cancel_delegation',
              'BandiFight_UpdateStats',
              'blockchainstudio_wit3',
              'esteem_point_transfer'
             ]

def process_operation(op):
    global ops
    global aggroed_ops

    ops += 1

    if op['type'] == 'custom_json':
        if op['id'] in op_ids:
            aggroed_ops += 1
            print(f"Total Ops: {ops} \nAggroed's Ops: {aggroed_ops} ({round(aggroed_ops/ops*100, 2)}%)")
        else:
            if op['id'] not in not_op_ids:
                print(op)


def main():
    stm = Steem()
    chain = Blockchain(stm, 'head')

    for op in chain.stream():
        process_operation(op)

if __name__ == '__main__':
    main()
```

# SQL Statements

#### Count transactions in last 30 days

```
select count(*)
from transactions
where block_num > 35262014
```

#### Find all SM & SE Transactions

```
select count(*)
from txcustoms
where tid in (
'scot_claim_token',
          'sm_find_match',
          'ssc-mainnet1',
          'sm_submit_team',
          'sm_open_pack',
          'sm_team_reveal',
          'sm_sell_cards',
          'sm_gift_cards',
          'sm_combine_cards',
          'sm_claim_reward',
          'sm_combine_all',
          'sm_enter_tournament',
          'sm_undelegate_cards',
          'sm_update_authority',
          'sm_start_quest',
          'sm_cancel_match',
          'sm_refresh_quest',
          'sm_purchase_record',
          'sm_cancel_sell',
          'sm_surrender',
          'sm_join_guild',
          'sm_purchase_orbs',
          'sm_open_all',
          'sm_burn_cards',
          'sm_market_purchase',
          'sm_token_transfer',
          'scot_payout_beneficiaries',
          'sm_price_feed',
          'sm_guild_contribution',
          'sm_gift_packs',
          'test-sm_price_feed',
          'sm_delegate_cards',
          'sm_purchase_item',
          'scot_set_vote',
          'scot_create_claim',
          'scot_claim',
          'scotauto',
          'sm_set_authority',
          'sm_card_award',
          'sm_tournament_checkin',
          'sm_update_price',
          'sm_leave_tournament',
          'sm_leave_guild',
          'sm_guild_remove',
          'sm_guild_promote',
          'sm_guild_invite',
          'sm_guild_decline',
          'sm_guild_accept',
          'sm_edit_guild',
          'sm_create_tournament',
          'sm_convert_cards',
          'sm_cancel_match',
          'sm_add_wallet',
          'sm_accept_challenge'
)
and timestamp > getutcdate() - 30
```

#### Find unique IDs for Steem Monsters

```
select distinct(tid)
from txcustoms
where tid like 'sm_%'
and timestamp > getutcdate() - 2
```

#### Find unique IDs for Scotbot

```
select distinct(tid)
from txcustoms
where tid like 'scot%'
and timestamp > getutcdate() - 2
```
